There's a 4pin blanked plug on lhs (as you sit) by the front light. I assume this is for the gps unit mounted on front fairing mount. (I don't have one) The wires are (looking at cross section from front of plug with clip on top. Red/Green Black Red/Black Grey/Green Anyone please shed a light as to which ones would be a switched +ve and which is the -ve? I'd like to use this for a usb plug for phone if that's possible. Plus anyone know where I can purchase these white/orangle 4 pin plugs? Thanks in advance.
Black should be negative Red/Black should be to fuse box number 1 Think the other two are Can hi and Can lo Multimeter should tell you. Should get continuity to earth on the black.
Thats the things. Excellent thanks Chris. I was looking for those everywhere but i got everything but. Kojaycat to be bookmarked.
Cheaper https://www.amazon.co.uk/Automotive-Connectors-04T-JWPF-VSLE-S-04R-JWPF-VSLE-S-Waterproof/dp/B07VTNJLY4
I now have all the parts, so will attempt to get it done weekend. Hopefully a usb supply (don't forget 2a fuse) that is live only with ignition.
The wires are (looking at cross section from front of plug with clip on top. Red/Blue Black Red/Black Grey/Green +ve Gnd Can + Can - +ve goes to Fuse 2. Incidentally a usb wire is Red White Green Black +ve Data - Data + Gnd
